Intel Server System MCB2208WFHY2 (WOLF PASS)
Popis a parametry
Intel Server System MCB2208WFHY2 (WOLF PASS)
| Code Name | Wolf Pass |
| Essentials | |
| Limited 3-year Warranty | Yes |
| Extended Warranty Available for Purchase (Select Countries) | Yes |
| ISV Certification | Designed for Microsoft Windows Server 2016* |
| Chassis Form Factor | 2U, Spread Core Rack |
| Board Form Factor | Custom 16.7" x 17" |
| Rack Rails Included | No |
| Compatible Product Series | Intel® Xeon® Scalable Processors |
| Socket | Socket P |
| Heat Sink | 2 |
| Heat Sink Included | Yes |
| System Board | Intel® Server Board S2600WF0 |
| Board Chipset | Intel® C624 Chipset |
| Target Market | Cloud/Datacenter |
| Rack-Friendly Board | Yes |
| Power Supply | 1300 W |
| Power Supply Type | AC |
| # of Power Supply Included | 2 |
| Redundant Fans | Yes |
| Redundant Power Supported | Yes |
| Backplanes | Included |
| Included Items | Intel® Server System R2208WF0ZS, Intel® Xeon® Gold 5118 Processor (x2), Intel® SSD DC P4600 2.5" 1.6TB (x2), HDD not included, Intel® SSD DC S3520 M.2 480GB (1), Remote Management Module Lite 2 AXXRMM4LITE2, 1300W AC CRPS 80+ Titanium Efficiency Power Supply Module AXX1300TCRPS, Intel® Ethernet Network Connection OCP X527-DA2 X527DA2OCPG1P5, 32GB DDR4, 288-pin, 2666MHz (x4), Trusted Platform Module 2.0 AXXTPMENC8, Intel® RAID Controller RS3UC080J (IT Mode), Oculink Cable Kit AXXCBL530CVCR, Oculink Cable Kit AXXCBL470CVCR |
| Supplemental Information | |
| Description | Cloud Blocks - Microsoft* includes Server Board, Chassis, Processor, Solid State Drives and third-party memory, optimized for Storage Spaces Direct and built with Microsoft* Windows* Server 2016 certified ingredients |
| Memory & Storage | |
| Storage Profile | Hybrid Storage Profile |
| Included Memory | 4x 32GB DDR4 2666MHz |
| Memory Types | DDR4 2666MHz |
| Max Memory Size (dependent on memory type) | 128 GB |
| Included Storage | Intel® SSD DC P4600 2.5" 1.6TB (x2), HDD not included, Intel® SSD DC S3520 M.2 480GB (1) |
| Max Storage Capacity | 12 TB |
| # of Front Drives Supported | 8 |
| Front Drive Form Factor | Hot-swap 2.5" |
| # of Rear Drives Supported | 0 |
| Processor Graphics | |
| Integrated Graphics ‡ | No |
| Expansion Options | |
| Connector for Intel® Integrated RAID Module | 1 |
| Riser Slot 1: Total # of Lanes | 24 |
| Riser Slot 2: Total # of Lanes | 24 |
| Riser Slot 3: Total # of Lanes | 12 |
| I/O Specifications | |
| # of USB Ports | 2 |
| Total # of SATA Ports | 12 |
| RAID Configuration | IT Mode |
| # of Serial Ports | 2 |
| Optical Drive Support | No |
| Package Specifications | |
| Max CPU Configuration | 2 |
| Advanced Technologies | |
| Intel® Optane™ Memory Supported ‡ | Yes |
| Intel® Remote Management Module Support | Yes |
| Integrated BMC with IPMI | IPMI 2.0 with OEM Extensions |
| Intel® Node Manager | Yes |
| Intel® On-Demand Redundant Power | Yes |
| Intel® Advanced Management Technology | Yes |
| Intel® Server Customization Technology | Yes |
| Intel® Build Assurance Technology | Yes |
| Intel® Efficient Power Technology | Yes |
| Intel® Quiet Thermal Technology | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® Rapid Storage Technology enterprise | Yes |
| Intel® Quiet System Technology | Yes |
| Intel® Fast Memory Access | Yes |
| Intel® Flex Memory Access | Yes |
| Intel® Transparent Supply Chain | |
| TPM Version | 2.0 |
.
ParametryPorovnání
Druh produktu
Platforma
Intel Server System MCB2208WFHY2 (WOLF PASS)
